Accueil > Liste de Produits > Machine d'impression d'écran > Imprimante multifonctions écran > Imprimante d'écran de bouteille pneumatique

Imprimante d'écran de bouteille pneumatique

  • $3776
    ≥1
    Set/Sets
Payment Type:
L/C,T/T,Western Union
Incoterm:
FOB,CIF,EXW,FCA,CPT
Min. Order:
1 Set/Sets
Delivery Time:
15 Days
Transportation:
Ocean
Port:
Shenzhen,Guangzhou,Hongkong
Share:
T'Chat
  • Description du produit
Overview
Product Attributes

ModèleS-220S

marqueKC

TailleB5

lieu d'origineAnguilla, Île de l'Ascension, Azerbaïdjan, Azerbaïdjan, Bahreïn, Bangladesh, Barbade, Chili, Îles Cocos (Keeling), Congo, République démocratique du, Costa Rica, Cuba, Danemark, République Dominicaine, Gabon, Allemagne, Grèce, Guadeloupe, Guernesey, Japon, Îles Heard et Mc Donald, Kenya, Indonésie, Luxembourg, France métropolitaine, Gambie, Honduras, Myanmar, Niue, l'ile de Norfolk, Norvège, Oman, Pologne

Industrie applicableFermes

Où fournir des services locaux (dans quels pays existe-t-il des points de service à l'étranger)Algérie, Afrique du Sud, Kazakhstan

Emplacement de la salle d'exposition (dans quels pays existe-t-il des salles d'échantillons à l'étranger)Canada

Supply Ability & Additional Informations

Détails d'emballageCaisse en bois

productivité50 sets / month

transportOcean

Lieu d'origineDongguan

Capacité d'approvisionnement50 sets/month

Certificats CE Certificate

HafenShenzhen,Guangzhou,Hongkong

Type de paiementL/C,T/T,Western Union

IncotermFOB,CIF,EXW,FCA,CPT

Délai de livraison15 jours

Packaging & Delivery
Selling Units:
Set/Sets
Package Type:
Caisse en bois

Échantillons montrent

screen-04

Description de la machine

S-220S Multi-function screen printing machine//Usage and characters

  • 220mm in diameter, suitable for printing less, hollow plastic bottles, hose, there is a slight taper of the hard and soft surface material color screen.
  • Used in baby bottles, cosmetic bottles, medicine bottles, filters, ignition and other hollow containers monochrome screen printing;
  • With surface UV curing machine M-1030UVS can be UV screen printing of plastic containers;
  • Solvent ink for screen printing, UV screen printing inks, screen printing ink printing a variety of functions;
  • Upper and lower part of table type surface screen printing machine, take place after the table automatically lifting the work piece;
  • You can use the foot switch for automatic operation, the safety factor greatly increased;
  • Multi-type screen printing machine, Both printing round objects and printing taper and flat objects, hardware replacement only way a simple gas conversion, will be able to achieve a multifunctional , and reduce costs.


Application


Plastics soft tubes, Bottles, containers, Bucket, Cosmetic case, any Cylinder-object, Oval-object.


S-220S Multi-function screen printing Machine //Parameters

  • Max. printing height: 320 mm;
  • Max. Printing diameter:;whole circle: 220 mm;.arc: 680 mm;
  • Max. printing speed: 1000 pcs/hr;
  • Air consume: 80 Litre/min(6bar).
  • Max Screen Frame: 850×450mm;
  • Stroke up-and-down of working table: 150mm;
  • Stroke up-and-down of Squeegee: 50mm;
  • Max length of printing objects: 400mm;
  • Range back-forth of Squeegee: 250mm;
  • Diameter of Fixture axis: 18mm;
  • Range back-forth of screen frame: 180mm
  • Works supply: 110V-220V Power supply;5-7 Bar compress air;
  • Package Dimension: 1130*1560*1360mm;
  • Gross weight: 190kg;
  • CBM: 2.3974
  • H.S.CODE: 8443198000
  • Certificate: CE


S-220S Multi-function screen printing Machine//Advantage


  • Choose clamp-type Workbench can be inflatable, or may not be blowing, can be placed all types of round, oval-shaped substrates;
  • Contact with the substrate , Working table up and down, to facilitate the placement of the substrates and removed;
  • High Precision axis control. Working table up and down, smooth running, accuracy up to 0.07mm;
  • High Precision axis control movement. Screen printing pressure is uniform and reliable, the accuracy up to 0.07mm;
  • Self-balance scraper technology and back blade, to ensure uniformity of ink, ink formation;
  • Microcomputer control program operations, set up a variety of modes;
  • Four counts digital LED count, high degree of automation;
  • Printed Stroke mechanical adjustments, adjust the speed of integrated circuit digital.
  • Around the screen frame, up and down the emblem of the tune, overlay accuracy, tuning and quick



Groupes de Produits : Machine d'impression d'écran > Imprimante multifonctions écran
