Machine d'impression d'écran de seau de peinture

Payment Type:
L/C,T/T
Incoterm:
FOB,CIF
Min. Order:
1 Set/Sets
Delivery Time:
15 Days
Transportation:
Ocean
Port:
Shenzhen,Guangzhou,Hongkong
Share:
T'Chat
  • Description du produit
Overview
Product Attributes

ModèleS-1200E

marqueKC

TailleB5

lieu d'origineAlgérie, Antigua-et-Barbuda, Australie, Bahamas, Azerbaïdjan, Bahreïn, Bangladesh, Barbade, les Îles Cook, La Croatie (nom local: Hrvatska), République Tchèque, Dominique, Equateur, Guinée Équatoriale, Ethiopie, Chypre, Érythrée, Estonie, Ethiopie, Îles Falkland (Malvinas), Îles Féroé, Fidji, Finlande, France, France métropolitaine, Indonésie, Luxembourg, France métropolitaine, Gambie, Honduras, Myanmar, Nicaragua, Niue, l'ile de Norfolk, Norvège, Oman, Philippines

Industrie applicableUsine d'aliments et de boissons

Où fournir des services locaux (dans quels pays existe-t-il des points de service à l'étranger)Algérie, Afrique du Sud, Kazakhstan

Emplacement de la salle d'exposition (dans quels pays existe-t-il des salles d'échantillons à l'étranger)Egypte

Supply Ability & Additional Informations

Détails d'emballageCaisse en bois

productivité50 sets / month

transportOcean

Lieu d'origineDongguan

Capacité d'approvisionnement50 sets/month

Certificats CE Certificate

HafenShenzhen,Guangzhou,Hongkong

Type de paiementL/C,T/T

IncotermFOB,CIF

Délai de livraison15 jours

Packaging & Delivery
Selling Units:
Set/Sets
Package Type:
Caisse en bois


Machine de sérigraphie multifonction S-1200E // Utilisation et caractères

Screen-54

  • 380mm in diameter, suitable for printing less, hollow plastic bottles, hose, there is a slight taper of the hard and soft surface material color screen.
  • Used in baby bottles, cosmetic bottles, medicine bottles, filters, ignition and other hollow containers monochrome screen printing;
  • With surface UV curing machine M-1030UVS can be UV screen printing of plastic containers;
  • Solvent ink for screen printing, UV screen printing inks, screen printing ink printing a variety of functions;
  • Upper and lower part of table type surface screen printing machine, take place after the table automatically lifting the work piece;
  • You can use the foot switch for automatic operation, the safety factor greatly increased;
  • Multi-type screen printing machine, Both printing round objects and printing taper and flat objects, hardware replacement only way a simple gas conversion, will be able to achieve a multifunctional , and reduce costs.

Application


Plastics soft tubes, Bottles, containers, Bucket, Cosmetic case, any Cylinder-object, Oval-object.


S-1200E Multi-function screen printing Machine //Parameters

  • Gear line width:14 mm, Length: 1200 mm;
  • Maximum printing thickness: 300 MM;
  • Air consumption: 80 Liter/Min;
  • The diameter of maximum printing workpiece: Φ380MM ;
  • The arc of maximum printing workpiece: 1150MM;
  • The maximum printing speed: 1100Pc/H;
  • Weight: 336kg.
  • Max Frame dimension: 750×1310mm;
  • Maximum Plain printing area:500×1150mm;
  • Max diameter of workpiece: Φ380MM
  • Works supply: 110V-220 V Power supply;5-7 Bar compress air;
  • Package size: 1820X1250X1650 mm;
  • Gross weight: 375KG;
  • CBM: 3.75T
  • H.S.CODE: 8443198000
  • Certificate: CE

S-1200E Multi-function screen printing Machine//Advantage

  • Choose clamp-type Workbench can be inflatable, or may not be blowing, can be placed all types of round, oval-shaped substrates;
  • Contact with the substrate , Working table up and down, to facilitate the placement of the substrates and removed;
  • High Precision axis control. Working table up and down, smooth running, accuracy up to 0.07mm;
  • High Precision axis control movement. Screen printing pressure is uniform and reliable, the accuracy up to 0.07mm;
  • Self-balance scraper technology and back blade, to ensure uniformity of ink, ink formation;
  • Microcomputer control program operations, set up a variety of modes;
  • Four counts digital LED count, high degree of automation;
  • Printed Stroke mechanical adjustments, adjust the speed of integrated circuit digital.
  • Around the screen frame, up and down the emblem of the tune, overlay accuracy, tuning and quick
